Zebra DS2208 Series Corded and Cordless 1D/2D

DS2208 Series Corded and Cordless 1D/2D Handheld Imagers

2D barcodes have made their way to your Point of Sale, appearing on everything from the items your customers are purchasing
to printed and electronic coupons and loyalty cards. Your 1D scanner can’t capture the new 2D codes, leading to exceptions that
slow down the check-out process and frustrate customers at that key last personal touchpoint in your store. But with the DS2200
Series, you can scan it all. You get an affordable 1D/2D imager that doesn’t compromise performance or features for price. Your
workers get best-in-class first-time, every-time scanning with point-and-shoot simplicity. You get an imager that couldn’t be easier to deploy and manage. And you can choose the model that best fits your POS needs — the corded DS2208 or the cordless
DS2278.* The DS2200 Series — the affordability your budget demands, with the deployment, ease of use and management
simplicity your business requires.

Specifications :

• Dimensions Corded DS2208

  • 6.5 in. H x 2.6 in. W x 3.9 in. D
  • 16.5 cm. H x 6.6 cm. W x 9.9 cm. D

• Supported Host Interfaces
  • USB, RS232, Keyboard Wedge, TGCS (IBM) 46XX over RS485
• Motion Tolerance (Handheld)
  • Up to 5 in./13 cm. per second for 13 mil UPC
• Swipe Speed (Hands-Free)
  • Up to 30.0 in./76.2 cm. per second for 13 mil UPC
• Light Source Aiming Pattern: Linear 624nm Amber LED
• Imager Field of View 32.8° H x 24.8° V Nominal
• Image Sensor 640 x 480 pixels
• Minimum Element Resolution
  • Code 39 - 4.0 mil; Code 128 - 4.0 mil;
  • Data Matrix - 6.0 mil; QR Code - 6.7 mil
• Environmental : Sealing IP42

Datasheet Zebra DS2208 seires
