OMRON Built-in Power Supply Photo Sensor E3JK-DR13-C 2M

Attribute:

Share

OMRON Photo Sensor E3JK-DR13-C 2M

OMRON Photo Sensor E3JK-DR13-C 2M



OMRON Built-in Power Supply Photo Sensor E3JK-DR13-C 2M

Diffuse-reflective, Sensing distance White paper 300 x 300 mm: 2.5 m, Light-ON/Dark-ON selectable, Relay output (SPDT), Pre-wired models (2 m), Infrared LED (850 nm)

Product Specifications :

  • Long sensing distance that is approximately 8 times that of our conventional model (for the Through-beam and Diffuse-reflective models).
    • (Through-beam: 40 m, Retro-reflective: 7 m, and Diffuse-reflective: 2.5 m.)
  • Improved visibility:
    • A red LED that makes the spot visible.
    • Large indicators that can be seen even from a distance.
  • Improved operability.
    • (Enlarged sensitivity adjuster and operation selector)
  • Freely selectable power supply input (24 to 240 VDC, 24 to 240 VAC).
    • (Additional types added to the DC type lineup.)
  • Models with infrared LEDs are also available.





Datasheet : OMRON Photo Sensor E3JK-DR13-C 2M






Ratings/Performance

Shape
Square type
Sensing method
Diffuse-reflective
Sensing distance
White paper 300 x 300 mm: 2.5 m
Differential distance
20% max. of sensing distance
Light source
Infrared LED (850 nm)
Power supply voltage
24 to 240 VAC±10% 50/60 Hz
24 to 240 VDC±10% ripple (p-p) 10% max.
Power consumption
2 W max.
Control output
Relay output (SPDT)
250 VAC 3 A (cosφ= 1) max.
5 VDC 10 mA min.
Life expectancy (relay output)
Electrical: 100 thousand times or more (switching frequency 1800 times/hour)
Mechanical: 50 million times or more (switching frequency 18000 times/hour)
Operation mode
Light-ON/Dark-ON selectable
Response time20 ms max.
Sensitivity settingSingle-turn adjustment
Ambient illuminance
Incandescent lamp: 3,000 lx
Sunlight: 11,000 lx
Ambient temperature range (Operating)
-25 to 55 (with no freezing or condensation)
Ambient temperature range (Storage)
-40 to 70 (with no freezing or condensation)
Ambient humidity range (Operating)
35 to 85% (with no condensation)
Ambient humidity range (Strage)35 to 95% (with no condensation)
Insulation resistance
20 MΩ min. (500 VDC megger)
Dielectric strength1500 VAC 50/60 Hz 1 min
Vibration resistance
Destruction: 10 to 55 Hz, 1.5 mm double amplitude each in X, Y, and Z directions for 2 h
Malfunction: 10 to 55 Hz, 1.5 mm double amplitude each in X, Y, and Z directions for 2 h
Shock resistance
Destruction: 500 m/s2 3 times each in X, Y and Z directions
Malfunction: 100 m/s2 3 times each in X, Y and Z directions
Degree of protection
IEC: IP64
Connection methodPre-wired models (Cable length 2 m)
IndicatorOperation indicator (orange), Stability indicator (green)
WeightPackage: Approx. 180 g
AccessoriesInstruction manual, Mounting bracket
Material
Case: ABS
Lens: Methacrylate resin
Display: Methacrylate resin
Adjustment: POM
Cable: Polyvinyl chloride (PVC)





OMRON Photo Sensor E3JK-DR13-C 2M

OMRON Photo Sensor E3JK-DR13-C 2M

OMRON Photo Sensor E3JK-DR13-C 2M
