HIP Mifare Reader CMS205 / MF Card Reader
Attribute:
Ultra-low power consumption: Standby current, less than 30mA, Output format: WG26/34, Card reading speed less than 1 second
Categories : SECURITY PRODUCT , Access Control ,
Share
HIP Mifare Reader CMS205M Card Reader (Support cards Mifare)
Wiegand Controller Access Control Door Card Reader is used to connect to the key card reader to add a card reading point or to swipe the card to exit instead of pressing the switch.
Description
- Ultra-low power consumption: Standby current
- Less than 30mA
- Output format: WG26/34
- Card reading speed less than 1 second
Specification
| | |
| Model | CMS205 | CMS205MF |
| Operating Voltage | 12VDC | 12VDC |
| Output format | WG 26 /WG34 | WG 26 /WG34 |
| Card type | ID 125 kHz | Mifare 13.56 MHz |
| Reading Distance | 30-60 mm | 30-60 mm |
| Idle Current | <80mA | <80mA |
| Operating | -45°C~60°C | -45°C~60°C |
| Temperature Operating Humidity | 0%-90% RH | 0%-90% RH |
| Waterproof | IP68 | IP68 |
| Dimension | 110*48*20mm | 110*48*20mm |
Datasheet : HIP Mifare Reader CMS205M
