Speed Gate Turnstiles Barrier Swing Gate Model LA3218

Attribute:

New automatic door that can prevent fingerprints and scratches on the body. The material is aluminum alloy to be a door to control entry and exit.

Share

Speed Gate Turnstiles Barrier Swing Gate Model LA3218





Speed Gate Turnstiles Barrier Swing Gate Model LA3218



Speed Gate Turnstiles Barrier Swing Gate Model LA3218
Prevent fingerprints and scratches on the body. Aluminum alloy material.



Speed gate is not only an entrance control management solution but also a vision image of company or application sites. Thus, it makes senses to color the turnstiles and attractive and comfortable for visitors at first glance. Aluminum alloy is better for powder coated and more light compared to stainless steel. Furthermore, this model of speed gates could be detached and assembling like block building. In this way, more products could be loaded in a container to save shipping costs.Meanwhile, it is much easier for installation,. Engineers could assemble in sites and install for commisioning. Indication Led lights flash to attract eyesights.

Product Features

  • Reasonable and reliable design, low noise, smooth operation and long service life;
  • With function of opening doors automatically under power-off state to meet the need of fire-fighting passage;
  • With functions of anti-tail, anti-reverse pass and so on;
  • Card can be set "with memory" or "without memory" functions;
  • With automatic reset function, i.e. after having access to the gate, the gate automatically restores to the locked state if not pass within the time set;
  • With infrared anti-clip function (anti-clip when gate is open or running);
  • Compatible with IC, ID card, scanning and face recognition,etc.
  • Two modes of operation are available: open or closed.
  • Various working modes are available, including two-way card reading and one-way card reading,etc






Product Details

  • Model Number : LA3218
  • Product Size : 600*130*980mm
  • Pass Width : 600-900mm
  • Thickness : 8/3mm
  • Material : 3.0mm  aluminum alloy
  • Infrared Sensor : 5 pairs
  • Pass rate : 35 p/m
  • Power Supply : 100-240V(AC)
  • Operational Voltage : 24V(DC)
  • Frequency : 50-60hz
  • Working Temperature : -25 to +70 ℃
  • MCBF : 10,000,000cycles






Datasheet : Speed Gate Turnstiles Barrier Swing Gate Model LA3218





ขนาดประตู

Speed Gate Turnstiles Barrier Swing Gate Model LA3218





Speed Gate Turnstiles Barrier Swing Gate Model LA3218





Speed Gate Turnstiles Barrier Swing Gate Model LA3218
